TY1 - 360 DEGREE WIFI CAMERA
Rs.5,000.00/-  Rs.6,000.00/-

( You Save Rs.1,000.00/-)

Minimum Order Quantity : 1   Get Latest Price

Specifications
Model Parameters
Model Model CS-TY1-B0-1G2WF
Camera
Image Sensor 1/3" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
Compression
Video Compression H.264
Video Bit Rate Adaptive bit rate.
Max. Resolution 1920 × 1080
Frame Rate Max:15fps; Self-Adaptive during network transmission
Network
Smart Alarm Motion detection
Wi-Fi Pairing AP pairing
Protocol EZVIZ Cloud proprietary protocol
Interface Protocol EZVIZ Cloud proprietary protocol
Interface
Storage MicroSD card slot (Max. 256GB)
Power Micro USB
Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard IEEE802.11b/g/n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps
Operating Environment
Temperature -10°C to 45°C (14°F to 113 °F)
Humidity 95% or less (non-condensing)
General
Power Supply DC 5V/1A
Power Consumption 5W max
IR Range MAX. 10 meters (32.81 ft.)
Dimensions 88 x 88 x 118.7 mm (3.46 x 3.46 x 4.67 inch)
Packaging Dimensions 103 x 103 x 186 mm (4.06 x 4.06 x 7.32 inch)
Net Weight 259g (9.14oz)
In the box:
In the box: TY1 Pan/Tilt Camera; Base; Screw Kit; Power Cable 3m (9.8 ft.); Drill Template ; Power Adapter ; Quick Start Guide
certificates：
certificates： FCC / UL / CE / WEEE / REACH / RoHS
